322152 - PCB 1071 - NORD-50 Data

Description

  • NORD-50 data interface.
  • Print: E   ECO: 1
  • Print: F   ECO: 0
  • PCB size 156 x 149 mm, 2 layers
  • Release date xx. xxx. xxxx

Chipset

  • None

LEDs

  • LED1 (Red)

Straps

  • None

Switches

  • Configuration (position A7), binary value (missing entries are illegal), only on PCB version F
    ConfigSW4SW3SW2SW1
    BOFFOFFOFFOFF
  • Configuration (position E1), binary value (missing entries are illegal), only on PCB version F
    ConfigSW6SW5SW4SW3SW2SW1
    BOFFOFFOFFOFFOFFOFF

Connectors

  • Standard NORD-10 bus
ND-322152
Component side, PCB version E

ND-322152
Solder side, PCB version E

ND-322152
Component side, PCB version F, old

ND-322152
Solder side, PCB version F, old

ND-322152
Component side, PCB version F, new (variant)

ND-322152
Solder side, PCB version F, new (variant)

ND-322152
Component side, PCB version F, new

ND-322152
Solder side, PCB version F, new

ND-322152
Defective parts tag from ND France
